mx181 toothbrush mxs184 jade MEIXIN brush making machine for sale

Company Advantages
1. Brush Making Machine is measured in brush making machine for sale. With 1 drilling and 1 tufting heads, one trimming knife, MX201 is designed for the straight strip brushes, whose length is available for customization
2. Our diverse backgrounds and paint brush making machine proficiency will allow us to build on the strengths of one another to bring you a strong company you can depend on as a business partner. Meixin's brush machine is 100% quality ensured, as have done a lot to raise quality levels and striven to establish a sound quality management and guarantee system.
3. toilet brush making machine provide paint brush ferrule making machine for a superior finish. With a perfect design, the machine offered by Meixin will not miss any hole in high production.
4. Our company has attained the product of patent certification and the CE certification, MEIXIN Is Able To Do Customized Designs Of Brush Making Machine.

 special features:

1. With one tufting heads,independent 4 axis motion,it used for small round toilet brush, others. It suitable for any plastic brush handles tufting.

2. The filament outside hole can be 15-30mm.

3.FMX fixture allows fast change over for a new brush tufted production. This machine with 2 grippers.

4.This machine with the new design of tufting.easy operate.

 A/ brand of motor in the machine

1.Delta inverter, Panasonic servo motor.

2.Taiwan TBI ball screw guide way and Taiwan HIWIN.

3.Schneider low voltage electrical appliances.

4.JAPAN CLOSE WITH BEARING.

5.Germany SENLIMA brake motor.

6.SHENZHEN ATECH controller

B/Controller features:

1. its provided with manual data input as well as teach in data input method.

2. auto or step operation.

3. speed of tufting is controlled by inverter for various speed adjustment.

4. test mode to test machine if functions properly.

5. editing features of ,delete or copy.

6. Normal working or positioning testing.

7. tufting excessive pressure alarm.

8. production speed is adjustable.

Item	Model	MX186
1	axis	4-axis
2	The stroke of X	50mm
	The stroke of Y	25mm
3	Tufting method	aluminum
4	Hole diameter	3-7mm
5	bristle container	Single or double colors
6	Application	to make toothbrush
7	The length of filament(divide)	8-15mm
8	Maximum Tufting Speed	9-10holes/second
9	head motor	servo motor
10	main power input	2 phase 220V,3phase 380vor220V
11	Drive motor	servo motor
12	Machine gross weight	850kg
13	Material of brush handle	Plastic
14	Material of brush material	Nylon,PVC,PP, or other fiber
15	Colors of filaments	Either single color and 2 colors
16	Tufting method	Flat wire or round wire
17	Air imput	1-8bar
18	machine size	1250*1300*1350mm
19	Controller gross weight	100Kg
20	productivity	5000pcs/10 hours

Company Features
1. MEIXIN BRUSH MAKING MACHINE FACTORYSpecialized In Brush Making Machine, Has Various Types Of paint brush making machine, brush making machine for sale For Buyers To Choose From.Please Send Us Your Sample Or Drawings, And Tell Us The Terms Of Business And Delivery Date.
2. Call Now! MEIXIN Is A Leading Supplier Of toilet brush making machine, paint brush ferrule making machine, paint brush making machine price In The Global Market. We'Re Your Best Choice For Purchasing This Product.
3. For More Detailed Information, Please Contact Us,The High Quality Brush Making Machine, brush making machine for sale Makes JIANGMEN MEIXIN COMB BRUSH MAKING MACHINE FACTORY A Best Seller In Industry, We Will Try Our Best To Comply With Your Request, Click Here For More Details About Our Product, Contact Now!
