MEIXIN brush making machine inquire now for PET brush1
- MEIXIN COMB BRUSH MAKING MACHINE, guided by customer needs, is committed to providing the best services for customers.
1. In the production process of MEIXIN brush making machine, various sophisticated equipment is used. The product will be finely processed under the jacquard knitting, wrapping circular knitting, rib knitting, or flat knitting machines.
2. With such characteristic, Industrial Roller Brush And Disc Brush Machines is an excellent brush making machine.
3. brush making machine has got the features of Industrial Roller Brush And Disc Brush Machines, which is worthwhile to popularized.
4. With this new technology product, fewer people are needed to manufacture. This will help manufacturers and manufacturers reduce labor costs.
3 axis disc brush drilling and tufting machine MX208
special features:
1. With the 1 drilling and 1 tufting heads.MX208 its designed for the industrial disc brush for the road and others industrial used. The dia of disc brushes and the filament outside the holes are available to make according to customers requirement.
2. It can be drilling ,tufting at the same time.
3.you can tuft the machine with bristle， PP,PET,others.
4. Independent 3 axis motion ,simple, stable.
5. Perfect design, wont be miss the holes and get high productivity .
A/ brand of motor in the machine
1. Delta inverter, Panasonic servo motor .
2. Taiwan TBI ball screw guide way and Taiwan HIWIN .
3.Schneider low voltage electrical appliances.
4.JAPAN CLOSE WITH BEARING.
5.Germany SENLIMA brake motor.
6.SHENZHEN ATECH controller
B/Controller features:
1. its provided with manual data input as well as teach in data input method.
2. auto or step operation.
3. speed of drilling and tufting is controlled by inverter for various speed adjustment.
4. test mode to test machine if functions properly.
5. editing features of ,delete or copy.
6. Normal working or positioning testing
7. drilling and tufting excessive pressure alarm
8. production speed is adjustable.
sure alarm
8. production speed is adjustable.
Company Features
1. JIANGMEN MEIXIN COMB BRUSH MAKING MACHINE FACTORY is one of China’s leading providers of brush making machine. We specialize in development, design, and manufacture.
2. We are not the only one company to produce brush making machine, but we are the best one in term of quality.
3. JIANGMEN MEIXIN COMB BRUSH MAKING MACHINE FACTORY's main force is to push Industrial Roller Brush And Disc Brush Machines. Inquiry! MEIXIN has been devoted to helping customers to enjoy brush making machine use experience. Inquiry!
2AXIS High speed brush tufting machine
Features :
1) It's used to tuft flat plastic brooms, the maximum tufting speed is 6.3 holes per second. Please note that the plastic broom blocks must be molded with holes in advance. It can also tuft other flat brushes, as long as operator changes grippers accordingly.
2) With 5.4'' touchable screen, the interface is available in various languages, such as Chinese, English, Spain, Russian, etc, as required by clients.
3) With PLC(Programmable Logic Controller), which operates precisely with excellent stability.
4) The working table of this broom machine is composed of straight-line guide rails and screw mandrels with high precision, which is quite stable and durable.
5) Two grippers are installed on worktable, which work alternatively and continually. Thus there's no need to stop to change brush blocks, which increases productivity.
6) Operator enters data for tufting positions under "Teach Mode". On operation interface, operator could insert, delete, adjust, copy, divide and move holes, which is quite simple and convenient.
Technical Parameter for 2-Axis High-Speed Brush Tufting Machine 2A-01:
Standard Working Area of 2-Axis | X-axis x Y-axis = 400mm x 200mm |
Material of Brush Handle | Plastic, wood |
Material of Brush Filaments | PP, PVC, PET, nylon |
Length of Filaments (Outside Holes) | 10mm - 120mm |
Diameter of Brush Filaments | 0.08mm - 1.2mm |
Diameter of Holes | 3mm - 6mm |
Colors of Filaments | Either single color or two colors |
Maximum Tufting Speed | 6-7 holes per second(depend on sample) |
Specifications of Machine Body | 1.20m(L) x 0.90m(W) x 1.68m(H) |
Motor (Power System) | With servo motors by default |
Data Input for Tufting Positions | Teaching-type: Operator manually puts tufting head into each hole, one by one, the position of these holes will be saved by computer one by one. By this way, all data for tufting position has been entered and saved. Digits-type: Operator manually enters digits(coordinates of X/Y axis) for tufting position. |
Touchable Screen | With 5.4'' touchable monitor controller; interface is in English or other language required by client, operating in dialogue-mode, which is quite simple and easy. |
Speed Adjusting | Frequency-conversion stepless-adjustable speed |
Qty of Programs Saved | It saves totally 80 programs for different broom models |
Gross Weight | Around 650KGS(with Controller box) |
Programming | PLC (Programmable Logic Controller) |
Power Supply | 1-phase 220V or 3-phase 380V, 50-60Hz, 600W |
Replaceable Grippers | Operator could make other flat brush models, as long as he changes grippers accordingly. |
Tufting Mode | Anchor-type (using flat wires) |
Packing | It'll be packed into wooden cases. |
A leader in this industry, specializing in brush making machine line for more than 37 years.
