brush making machine for sale head machine 1head MEIXIN

Company Advantages
1. JIANGMEN MEIXIN COMB BRUSH MAKING MACHINE FACTORY's offered Brush Making Machine are manufactured using the finest brush making machine for sale and advanced instruments that enable us to produce world class product.
2. JIANGMEN MEIXIN COMB BRUSH MAKING MACHINE FACTORY is leading manufacturer and exporter of paint brush making machine and our product is made up of good quality. During the past few years, our No. 1 priority has always been customer service and customers satisfaction, which resulted in high recognition and satisfaction from the customers
3. Moreover, these toilet brush making machine are available in very reasonable price. Over the years, meixin has greatly improved the service system so that we can provide one-step and professional services for customers for their full satisfaction
4. Meixin is capable of designing and manufacturing products with both standard and customized specifications, MEIXIN Is A Leading Brush Making Machine, paint brush ferrule making machine Company, Who Has Strong Desire To Offer High Quality Product.
5. Meixin's offer of high speed machines are used to produce many kinds of household brushes, such as, toilet brushes, brooms, hockey brush, hair brush, bottle brush in any shape as well as industrial brushes like roller brush,disc brush for road, and other shape of brushes, MEIXIN Is An Exporter Which Handle Sorts Of paint brush making machine With Rich Experience.

 special features:

1. With one tufting heads,independent 4 axis motion,it used for small round toilet brush, others. It suitable for any plastic brush handles tufting.

2. The filament outside hole can be 15-30mm.

3.FMX fixture allows fast change over for a new brush tufted production. This machine with 2 grippers.

4.This machine with the new design of tufting.easy operate.

 A/ brand of motor in the machine

1.Delta inverter, Panasonic servo motor.

2.Taiwan TBI ball screw guide way and Taiwan HIWIN.

3.Schneider low voltage electrical appliances.

4.JAPAN CLOSE WITH BEARING.

5.Germany SENLIMA brake motor.

6.SHENZHEN ATECH controller

B/Controller features:

1. its provided with manual data input as well as teach in data input method.

2. auto or step operation.

3. speed of tufting is controlled by inverter for various speed adjustment.

4. test mode to test machine if functions properly.

5. editing features of ,delete or copy.

6. Normal working or positioning testing.

7. tufting excessive pressure alarm.

8. production speed is adjustable.

Item	Model	MX186
1	axis	4-axis
2	The stroke of X	50mm
	The stroke of Y	25mm
3	Tufting method	aluminum
4	Hole diameter	3-7mm
5	bristle container	Single or double colors
6	Application	to make toothbrush
7	The length of filament(divide)	8-15mm
8	Maximum Tufting Speed	9-10holes/second
9	head motor	servo motor
10	main power input	2 phase 220V,3phase 380vor220V
11	Drive motor	servo motor
12	Machine gross weight	850kg
13	Material of brush handle	Plastic
14	Material of brush material	Nylon,PVC,PP, or other fiber
15	Colors of filaments	Either single color and 2 colors
16	Tufting method	Flat wire or round wire
17	Air imput	1-8bar
18	machine size	1250*1300*1350mm
19	Controller gross weight	100Kg
20	productivity	5000pcs/10 hours
